Original operating manual
Technical data
Chain mortiser CM 150
Voltage 220 - 240 V ~
Frequency 50/60 Hz
Rated input 2 000 W
Power output 1 400 W
Lateral guide 0 - 150 mm
Mortising depth 0 - 100 mm/
0 - 150 mm*
Grooving depth 0 - 400 mm
Drive sprocket speed 4 250 rpm
Weight 8,5 kg
Safety Class II /
* with the guide frame GM 145 only
1 Symbols
Double insulation
Warning of general danger
Risk of electric shock
Read the operating instructions/notes!
Wear protective goggles.
Wear a dust mask!
Wear ear protection!
Wear protective gloves!
Do not throw in the household waste!
Advice or tip
2 Included in the delivery:
1 Complete chain cutting tool,
1 Lateral guide,
1 Spanner 19 DIN 894,
1 Double-sided spanner 10/13 DIN 895,
1 Hexagon key 6 DIN 911,
1 Operating Manual
3 Operating controls & Description
1. Mains switch actuator
2. Lock-off button
3. Hand screw
4. Safety guard
5. Hexagon nut
6. Locking nut
7. Chain tensioning screw
8. Roller bearing
9. Stauffer lubricator
10. Depth gauge
11. Locking lever for depth gauge adjustment
12. Lateral guide
13. Locking lever for lateral guide adjustment
14. Tubular spirit level
15. Splinter guard fi xing screw
16. Splinter guard
17. Sight window
18. Brush cap
19. Carbon brushes
The accessories shown or described in this Op-
erating Manual may not be included as a part of
delivery.
4 Intended use
The chain mortiser is designed exclusively for
mortising and cutting grooves in solid wood.
Any other usage is to be considered not within the
intended range of application. The manufacturer is
not liable for damages resulting from such usage
and the user is the only one to be held responsible
for the risks involved. Observation of the condi-
tions for operation, maintenance and servicing
prescribed by the manufacturer makes part of the
intended range of application.
The chain mortiser may only be used, maintained
and serviced by such persons who are competent
for this, who are familiar with the electric tool and
have been informed about all the dangers con-
cerned.
For free-hand mortising, use only chain cutting
tools designed for maximum mortising depth of
100 mm. The range of applications and operation
modes may be extended by using the accessories
listed in this Operating Manual.
The user is solely liable for damage and accidents
caused by improper use of the product.
For safe work with this electric tool and preven-
tion of injury, it is imperative to follow all generally
accepted safety principles and regulations for pre-
vention of accidents, and read the enclosed „Safety
instructions“ thoroughly.
The manufacturer disclaims liability for
damages caused by unauthorized modifi -
cations or using other than the supplied
or specifi ed accessories with the electric
tool.
