4 Parts of the machine
[1-1]
Electrical outlet module
[1-2]
Cable and accessory holder
[1-3]
Suction hose mount
[1-4]
Handle
[1-5]
Lock
[1-6]
Filter drawer
[1-7]
Locking clip
[1-8]
Exhaust opening
[1-9]
Dirt trap
[1-10]
On/off switch
[1-11]
MAN button
[1-12]
Suction power adjustment
The specified illustrations appear at the begin
ning of the Operating Instructions.
5 Technical data
Mobile dust extractors
Power consumption 2.9 - 10 A (350 –1200 W)
Max. electrical outlet module connected load. 2 A (240 W)
Max. suction capacity (air), extractor/turbine 130 m³/h (4591 cu.ft./h) / 222 m³/h (7840
cu.ft./h)
Max. vacuum, turbine 24000 Pa
Filter surface area 3898 cm² (604.2 sq.in.)
Suction hose 27 mm x 3.5 m (1-1/16 x 11.5")
Mains power cable length 5.5 m (18 ft.)
Sound pressure level as per EN 60335-2-69/uncertain
ty K
70 dB(A)
Hand-arm vibration value as per EN 60335-6-69/
uncertainty K
< 2.5 m/s² / 1.5 m/s²
Degree of protection IP X4
Container capacity 15 l (4 gal.)
Dimensions LxWxH 470x320x435 mm (18.5 x 12.6 x 17.1 in.)
Weight 11.2 kg (24.7 lbs)
6 Intended use
Mobile dust extractor suitable for
– Extracting non-hazardous dust, dirt, sand
and chips,
– Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
This extractor has been tested in accordance
with EPA RRP. The HEPA Filter is tested and
certified in accordance with IEST RP-CC-001, to
filter and exhaust air particles to 0.3 microns
with at least 99.97 % efficiency with no bypass
leakage.
The mobile dust extractor is only suitable for
indoor use.
The user is liable for improper or non-in
tended use.
7 Operation
WARNING
Unauthorised voltage or frequency!
Risk of accidents
► Observe the specifications on the ma
chine’s name plate.
► Observe country-specific regulations.
7.1 Initial commissioning
► Insert the filter bag [2].
► Connect the suction hose[3]
.
English
10
