Festool CTL SYS Original Instructions

[1-6]
T-Loc lock for Systainers
[1-7]
Cold-device plug
[1-8]
On/off switch
[1-9]
AUTO/MAN switch
[1-10]
Electrical outlet module
The specified figures appear at the beginning of
the operating manual.
6 Commissioning
WARNING
Unauthorised voltage or frequency!
Risk of accidents
► Observe the specifications on the ma
chine's name plate.
► Observe country-specific regulations.
6.1 Connect dust extractor
WARNING
Risk of injury from tools starting up unex
pectedly
► Before switching on ensure that the con
nected tool is switched off.
► Insert the mains power cable in the cold-
device connector [2] and in an earthed sock
et.
► Lay the mains cable through the recess [2].
The switch [1-8] serves as an on/off switch.
Using the [1-9] switch, switch between the AU
TO and MAN settings.
"MAN" switch position
Appliance socket [1-10] is not connected to the
power, the dust extractor starts.
"Auto" switch position
Appliance socket [1-10] is connected to the
power, the dust extractor starts when the con
nected tool is switched on.
Pull the plug from the socket when the
machine is not in use and prior to main
tenance and cleaning work.
6.2 Connecting electric power tools
WARNING
Risk of injury
► Observe the maximum appliance socket
connected load (see chapter "Technical da
ta")
► Switch off the electric power tool.
► Connect the electric power tool to the appli
ance socket .
6.3 Connecting the suction hose
at the extraction opening [3a]
►
► Connect the suction hose to the elbow at the
extraction opening.
at the exhaust opening [3b]
► Open flap at rear of dust extractor.
► Connect suction hose to elbow at exhaust
opening.
7 Settings
7.1 Temperature monitoring
Before reaching a critical temperature, the
temperature monitor switches off the dust ex
tractor.
► Before reaching a critical temperature, the
temperature monitor switches off the dust
extractor.
► Switch off the dust extractor, allow to cool
for about 5 minutes, then switch on again.
Not possible to switch on: Contact Festool
customer service workshop.
7.2 Connect with the T-Loc
The dust extractor can be closed, opened and
connected by turning the T-Loc:
– Close dust extractor [4a].
– Open dust extractor [4b].
– Connect dust extractor to storage box [4c].
Before lifting, always close the T-Loc at
the dust extractor or connect to the stor
age box and check for secure holding.
Max. load for connection to other Systainers: 20
kg
7.3 Use/Adjust carrying strap
Max. permissible load of carrying strap: 20 kg
The carrying strap can be attached in two dif
ferent positions:
– Carrying the dust extractor: Carrying strap
at dust extractor [5a]
English
15

Festool CTL SYS Specifications

General

Input power	1200 W
Airflow	50 l/s
Capacity	4.5 L
Filter surface	5357 cm²
Container capacity (dust)	3.5 L
Product color	Black, Green, White

Weight and Dimensions

Depth	396 mm
Width	296 mm
Height	270 mm
Weight	6900 g
