16
CLEANTEX CTM/ CTM AC
GB
the safe method of removal and disposal of
the material collected.
– For reasons of safety, never operate the
machine from an unearthed socket.
– Always use the machine socket for the pur-
pose specified in the manual.
– Always use original Festool accessories.
– Pull the plug from the socket when the ma-
chine is not in use and prior to mainte-
nance and cleaning work.
– Do not lift or transport the machine by the
handle using a crane or lifting gear.
6 Operation
6.1 Initial operation
X
Open the locking clips [2-2] and remove
the top section of the machine[2-1].
X
Remove the accessories from the dust
container [2-3] and the packaging!
X
Insert a filter or disposal bag in the dirt
trap (see chapter 7.7 and 7.8).
X
Replace the top section [2-1] and close
the locking clips [2-2].
X
Attach the cable holder to the rear of the
mobile dust extractor (see Fig. [3]).
X
Connect the suction hose to the machine.
6.2 Switch on/off
X
Insert the plug into an earthed socket.
The switch [1-11] serves as an on/off switch.
Switch position "0"
Appliance socket [1-4] is disconnected from
the power, mobile dust extractor is switched
off.
"MAN" switch position
Appliance socket [1-4] is connected to the
power, the mobile dust extractor starts.
"Auto" switch position
Appliance socket [1-4] is connected to the
power, the mobile dust extractor starts when
the connected tool is switched on.
7 Settings
7.1 Adjusting the hose diameter
X
Adjust the hose diameter adjuster [1-9]
to match the diameter of the connected
hose.
L
The monitoring devices will measure the
air speed in the extractor hose correctly
as a result (see chapter 7.9).
7.2 Connecting electric power tools
X
Connect the electric power tool to the ap-
pliance socket [1-4].
7.3 Connecting pneumatic tools
If the compressed air module [1-3] (496141;
included in scope of delivery of CTM 36 E LE,
CTM 36 E LE AC, CTM 48 E LE, CTM 48 E LE
AC) is installed, the automatic switch-on
function of the mobile dust extractor also
works in combination with air tools.
WARNING
Unauthorised voltage or frequency!
Risk of accident
X
The mains voltage and the frequency of
the power source must correspond with
the specifications on the machine's name
plate.
X
In North America, only Festool machines
with the voltage specifications 120 V/60
Hz may be used.
WARNING
Risk of injury from tools starting up un-
expectedly
X
Before setting the switch to the "AUTO" or
"MAN" position, make sure that the con-
nected tool is switched off.
WARNING
Risk of injury
X
Observe the maximum connected loads
for the appliance socket (see chapter
"Technical data").
X
Make sure that the power tool is switched
off before connecting or disconnecting.
WARNING
Risk of injury
X
Make sure that the pneumatic tool is
switched off before connecting or discon-
necting.
