18 Pneumatics diagram parts list
The pneumatics diagram appears at the end of this operating manual (applies for EW/DW versions only):
Name Version Quantity Pt. no. Designation,
type
Notes,
supplier
0V1 EW/DW TURBO/A 1 495435 Compressed air module
EW/DW TURBO
Festool
EW/DW TURBO/M;
EW/DW CT/SRM/M
1 495808
0Z1 All 1 495434 Combination of mainte-
nance devices
FRD-1/2-D-MIDI
Festo no.: 159584/
159592/192576
Festool
0Z2 All 1 E036905 Quick safety coupling
SSK-NW7.8-G1/4a
Unlubricated output
Cejn
0Z3 All 1 475165 Safety coupling
ERG 071 152
Lubricated output
Prevost
0Z4 All 1 475165 Safety coupling
ERG 071 153
Lubricated output
Prevost
1A1,
2A1
EW/DW TURBO/A 2 475153 Double action cylinder
ADN-20-60-I-P-A
FESTO no.:
536 365
FESTO
1S1,
2S1
EW/DW TURBO/A 2 475535 Microswitch, NOC
D2VW-01L3-3HS (CHN)
Omron
2S2 All 1 452117 Reed contact
MK3-1A71-BV 588
Pneumatic tool 2
Meder
1V1,
2V2
EW/DW TURBO/A 2 475154 Monostable 5/2-way valve
CPE10-M1BH-5L-M7
FESTO no.:
196 927
FESTO
1S2 All 1 452117 Reed contact
MK3-1A71-BV 588
Pneumatic tool 1
Meder
