Festool SYSLITE DUO - Floodlight Features and Operation; Component Identification; Powering and Temperature Control; Setup, Mounting, and Suspension

9
DUO
Flood light S Y S L I T E DUO
Color rendering
index
>80
Lifespan (L70) > 10,000 h
Weight 3.4 kg
Protection type IP 55
5 Machine features
[1-1] Detachable stand, cable spool
[1-2] Luminous area
[1-3] Handle
[1-4] Wall peg, cable clam
[1-5] Mains power cable
6 OPERATION
WARNING
Unauthorised voltage or frequency!
Risk of accidents
X Observe the specifications on the machine’s
name plate.
X Observe country-specific regulations.
6.1 Switching on/off
Switching on the device
The power plug of the device may not
be plugged in in a moist environment,
as it does not feature a proofing
against dampness.
X Insert mains plug into socket.
Light cone appears instantly.
Switching off the device
X Unplug the mains plug.
X Coil mains cord on the stand [1-1]. Pin the
end of the cable into the clam [2-1].
6.2 Temperature surveillance
When exceeding the temperature limit, the
device automatically reduces luminosity. If device
continually exceeds temperature limits, power is
cut off completely.
Measures for restoring luminosity:
X Pull mains plug,
X remove cause of overtemperature (i. e.
obstructed air vents),
X reinsert mains plug.
Full luminosity is restored.
7 Setup
Always set up device with stand to
keep airvents air accessible [4-1].
Place on dry, even and stable surface. Do not
suspend device from its power cord. Electrical
hazards by overstraining the power cord may
occur. Prevent obstruction of the cooling slits on
top and bottom of the device.
0,2m
Minimum distance to illuminated sur-
faces and combustible materials 0,2m.
Set up angles [3]
Device may be set up in three different angles.
8 Affixing to surfaces [4]
For securer mounting the device is outfitted with
a detachable stand [4-2] that includes bolt holes
[4-3] for secure attachment to surfaces.
X Pull off stand. Begin by pulling more strongly
on one side.
X Evenly pull off stand.
X Affix stand to surface.
Do not affix device to vertical sur-
faces (walls etc.) as this significantly
reduces the cooling performance of
the air vents.
X Mount device on stand.
9 Set up with tripod [5]
Use device only with the Festool tripod
STDUO 200. Tripod height may not
exceed 2.0 m. Observe the instructions
in the tripod manual.
X Expand tripod legs completely [5].
X Mount device on tripod.
X Swivel flood light until catch snaps into place.
10 Suspend
10.1 from wall [6]
Use wall peg [2-1] on rear side of device. Place on
nail or screw head which protrudes from a wall.
