9
Tripod
A standard photographic tripod with UNC
1/4"-20 thread can be attached to the
threaded tripod socket
[6-1]
.
Magnetic foot with spherical head (part
accessories) [7]
Strong magnetic fields
may damage or destroy
electronic or mechanical
elements and devices The same also ap-
plies to
cardiac pacemakers
. The re-
quired safety distances can be found in
the manuals of these devices.
Risk of pinching fingers and
hands at the magnet!
Check the area at the magnetic foot
before use and clean if necessary.
Only use the magnetic foot for securing
the Festool working light using one of the
options described below:
Screw on magnetic foot at the tripod
socket
[6-1]
. This can be rotated in all di-
rections by loosening the clamping
screw
[7-1]
.
Secure the magnetic foot using one of
three options:
Secure with a clamp
