5
4Technical data
5 Functional description
The pictures for the functional descrip-
tion are on a fold-out page at the begin-
ning of the instruction manual. While
reading the manual you can fold out the
page for comparison and quick refer-
ence.
* not on all versions included in the
scope of delivery
6Operation
6.1 Charging the integral battery
pack
Prior to initial operation:
charge
battery pack for approx. 4 h!
Compact working light KAL II
Rated voltage / capacity of integral battery (LiIon) 7,2 V = / 2,9 Ah
Rated voltage with external Festool battery pack 10,8 - 18V =
Charging socket voltage range 7,2 - 18 V =
Lighting device 12x 1.5W Power LED
Light duration (internal bat-
tery)
Min. light: Stage 1 (30%) 5 h 30 min.
Max. light: Stage 2 (100%) 2 h 10 min.
Luminous flux, brightness Min. light: Stage 1 (30%) 310 Lumen
Max. light: Stage 2 (100%) 769 Lumen
Charge time of internal battery 90% / 100% 2 h 40 min / 3 h 20 min.
Permitted operating temperature range -5 °C to +55 °C
Permitted battery temperature for charging 0 °C to +45 °C
Weight (without external battery pack) 0,7 kg
Protection type IP 2X
- +
[1-1]
Charging state indicator LED
[1-2]
On/off switch with 3 settings
[1-3]
Folding attachment handle
[1-4]
Connecting socket for charging
adapter
[1-5]
Magnetic foot with spherical head*
[1-6]
Adapter plate*
[1-7]
Mains charging adapter*
[1-8]
Vehicle charging adapter
