FFA FFA-10000 - Mains power connection

Warning! This appliance must be earthed at all times.
The FFA-4004 and FFA-6004 have a single Neutrik powercon power inlet which requires a maximum of 16A, 230V ac 50/60 Hz.
The FFA-6000, FFA-8000 and FFA-10000 amplifiers have two individual power supplies fitted with a Neutrik powercon mains inlet for
each amplifier channel. Two 16A 230V ac circuits are required per FFA-6000, FFA-8000 and FFA-10000 amplifier. Total 32A 230V ac.
The 2 amplifier channels are totally independent of each other and should a channel fail this will not affect the other channel.
The amplifier must be connected to an AC source with a three wire cable as supplied with the amplifier. The rack the amplifier is
mounted in must also be connected to the same grounding circuit. The amplifier must not be used if the earth connection is
not properly terminated – this is very important for personal safety and system ground control.
The wires in the mains lead are colour coded:
green and yellow = earth
blue = neutral
brown = live
Mains power supply requirement
FFA-4004 – 16A max
FFA-6004 – 16A max
FFA-6000 – 2 x 16A max
FFA-8000 – 2 x 16A max
FFA-10000 – 2 x 16A max
Power operational range
230V ac 50/60 Hz +- 10%
Mains power connection
TO REDUCE THE
RISK OF ELECTRIC
SHOCK, THE GROUND
CONNECTION WITH
THE AC PLUG MUST
BE MAINTAINED
REPLACE ONLY WITH
SAME TYPE FUSE
AC INPUT 220-240 VAC 50/60 Hz
DO NOT OBSTRUCT VENTS
TO REDUCE THE
RISK OF ELECTRIC
SHOCK, THE GROUND
CONNECTION WITH
THE AC PLUG MUST
BE MAINTAINED
REPLACE ONLY WITH
SAME TYPE FUSE
AC INPUT 220-240 VAC 50/60 Hz
DO NOT OBSTRUCT VENTS
