PowerWizard 1.0 & 2.0 Control Systems User Manual
6
1.4 PowerWizard Control Module Description
Figure 2: PowerWizard Control Module Description
Display screen
AC overview hot-key
DC overview hot-key
Warning lamp
Shutdown lamp
Alarm acknowledge
Lamp test
Run
Auto
Stop
Up cursor
Escape
Right cursor
Enter
Down cursor
Left cursor
