Internal Layout
The door shelves can be easily removed for cleaning
Hold the door shelf at the sides and push it upwards to release it from
its seat, then pull it outwards.
Reverse the procedure to reinstall
Door Shelves
The shelves are sliding and easily positioned by the user as follows:
pull and slightly turn the locking knob
lift the front part of the shelf and tilt it
lift or lower the shelf to the desired position
reposition the locking knob
to remove a shelf it is necessary to first remove the end parts of the
guides (unscrew the locking nut), slide it downwards and remove it.
Shelves
Located in the upper drawer of the freezer compartment
after removal, make sure to reposition it correctly.
Ice Tray
Do not place hands or fingers near the Icemaker
when in function.
