FHM SG24 - Page 12

Farmer-HelperSG24 Stump Grinder 12 Revision 12-12-2017
NO. PART NO. Name & Specifications Quantity
1
GB /T5783-2000
Bolt M8×20 3
2 GB/ T93-1987 Spring washer 8 3
3
GB /T97 .1-2002
Plain washer 8 3
4 SG24.01.011 Pin weldment 3
5 SG24.01.012 Swing frame weldment 1
6 JB/T7940.1-1995 Oil cup M8 4
7 SG24.01.013 Pivot cross 1
8 SG24.01.014 3-Pt. toke weldment 1
9 Lock pin 2
10 SG24.01.101 Pin for lifting 2
11 SG24.01.015 Hose, Horizontal 2
12 SG24.01.016 Hydraulic cylinder, Horizontal 1
13 JB/T 982-1977 Gasket 16 8
14 BH5.60.110 Hollow bolt 16 2
15 GB /T91-2000 Cotter pin 5×40 2
16 SG24.01.102 Pin 2
17 SG24.01.017 Hydraulic cylinder 1
18 SG24.01.103 Sleeve 2
19 BH5.60.108 Ball adapter 4
20 JB/T 982-1977 Gasket 14 4
21 MK6 Throttle valve 2
22 BH5.60.109 Adapter 14-14 2
23 SG24.01.018 Hose 2
