FHM SG24 - Page 14

Farmer-HelperSG24 Stump Grinder 14 Revision 12-12-2017
NO. PART NO. Name & Specifications Quantity
1
GB ／T5783-2000
Bolt M8×20 7
2
GB/ T93-1987 Spring washer 8 7
3
GB ／T97 ．1-2002
Plain washer 8 7
4
SG24.02.011 Pin weldment 1
5
JB/T7940.1-1995 Oil cup M8 1
6 SG24.02.012 Carbide tooth weldment
36 (SG24)
54 (SG24-PRO)
7
SG24.02.013 Housing weldment 1
8
SG24.02.014 Grinder wheel weldment, SG24 1
SG24-PRO.02.014 Grinder wheel weldment,
SG24-PRO
1
9
GB/T6178-1986 Slotted nut M24 1
10
SG24.02.015 Wheel guard weldment 1
11
SG24.02.016 Guard weldment 1
12
SG24.02.101 Sleeve 2
13
GB ／T96.2-2002
Plain washer 12 2
14
GB/ T93-1987 Spring washer 12 2
15
GB ／T5783-2000
Bolt M12×35 2
16
GB ／T5783-2000
Bolt M10×25 12
17
GB/ T93-1987 Spring washer 10 12
18
GB ／T97 ．1-2002
Plain washer 10 12
19
GB ／T889 ．1-2000 Lock nut M16 4
20 GB/ T93-1987 Spring washer 14
36 (SG24)
54 (SG24-PRO)
21
GB ／T6171-2000
Nut M14*1.5
36 (SG24)
54 (SG24-PRO)
22
SG24.02.018 Pin 2
23
SG24.02.017 Lid, shield 1
24
GB ／T5783-2000
Bolt M16×50 4
25
XH50.169Z.01L
Gearbox assembly (1 ：1.77)
1
