7
Elektra Compact 18 kW BP-L 016 18 kW maximum electrical output
Single-phase electrical supply: 230-240 V - 50 Hz.
Weight: 60 kg.
Capacity of tank 37 liters. Glass-lined steel with inspection flange and
magnesium anode.
Electrical / heat power available at heating of 18 kW obtained by n°.3
Resistance group (n°.3 da 3x2 kW).
Electrical power at hot water resistance of 2 kW (2.000 W).
Maximum head available at the pump of 7 m.c.a.
Expansion vessel capacity of 10 liters.
Safety valve of heating circuit of 0,3 MPa (3 bar).
Safety valve of sanitary circuit of 0,65 MPa (6,5 bar).
Maximum heating operating pressure: 0,25 MPa (2,5 bar).
Maximum sanitary operating pressure: 0,55 MPa (5,5 bar).
Minimum operating pressure in the heating circuit: 0,06 MPa (0,6 bar).
Mini. operating pressure in the sanitary, comfort system: 0,025 MPa (0,25 bar).
Min. op rating pressure in the sanitary, economy system: 0,005 MPa (0,05 bar).
Maximum limit of thermal safety heating circuit - boiler body: 100°C.
Elektra Compact 24 kW BP-L 016 24 kW maximum electrical output
Single-phase electrical supply: 230-240 V - 50 Hz.
Weight: 61 kg.
Capacity of tank 37 liters. Glass-lined steel with inspection flange and
magnesium anode.
Electrical / heat power available at heating of 24 kW obtained by n°.4
Resistance group (n°.4 da 3x2 kW).
Electrical power at hot water resistance of 2 kW (2.000 W).
Maximum head available at the pump of 7 m.c.a.
Expansion vessel capacity of 10 liters.
Safety valve of heating circuit of 0,3 MPa (3 bar).
Safety valve of sanitary circuit of 0,65 MPa (6,5 bar).
Maximum heating operating pressure: 0,25 MPa (2,5 bar).
Maximum sanitary operating pressure: 0,55 MPa (5,5 bar).
Minimum operating pressure in the heating circuit: 0,06 MPa (0,6 bar).
Mini. operating pressure in the sanitary, comfort system: 0,025 MPa (0,25 bar).
Min. op rating pressure in the sanitary, economy system: 0,005 MPa (0,05 bar).
Maximum limit of thermal safety heating circuit - boiler body: 100°C.
