Audible And Visual Signals Supplied By The Rear Park Assist System.
SIGNAL MEANING INDICATION
Obstacle Distance
An obstacle is present within the
sensors’ field of view
Audible signal (dashboard loudspeaker)
• Sound pulses emitted at a rate that in-
creases as the distance decreases.
• Emits continuous tone at 12 in (30 cm)
• Adjustable volume level. (Refer to
“Menu Functions” for further information).
Failure Sensor or System failures
Visual Signal (instrument panel)
• Icon appears on display.
• Message is displayed on multifunction
display (where provided).
While audible signals are emitted, the audio system is not
muted.
The audible signal is cut out immediately if the distance
increases. The tone cycle remains constant if the distance
measured by the inner sensors is constant. If this condi-
tion occurs for the external sensors, the signal is cut off
after 3 seconds (stopping warnings during maneuvers
parallel to walls).
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
