Centre sliding seat (where provided)
Lift the lever (A) and push the seat forwards or backwards. After
releasing the lever, make sure the seat is correctly locked on the runners.
Moving the seats
To increase the boot load capacity the seats have two positions (three
for the centre seat).
To move the seats forward from the standard position, use the special
anchorages on the floor.
To set the centre seat in the most forward position (maximum load
position), bring the centre front seat fully forward and tip the seatback
over.
At this point, refit the rear seat, positioning the seat back as shown in the
figure in its most forward position.
The central seat can be moved backwards by 100 mm.
A - all forward position
B - standard position
C - all backward position
F0E0016m
F0E0232m
F0E0015m
