E-DUCATO
Securing the vehicle
17
4.4 Stabilisation
To stabilise the vehicle, support it at all four points (A) under the
front and centre pillars, using wooden blocks or equivalent objects.
When using a hoist, use points (B).
A: support points
B: support points with lift
4.5 Securing a vehicle safe after a breakdown
IMPORTANT
IMPORTANT INFORMATION FOR DEACTIVATING THE HIGH-
VOLTAGE SYSTEM
• Use personal protective equipment (see Chap. 3)
• DO NOT CUT OR TAMPER WITH ORANGE CABLES AND
CONNECTORS
The orange cables and components connected to these cables
are part of the high-voltage system and may be energised.
• The energy is still present in the high-voltage battery.
• THE HIGH VOLTAGE MAY REMAIN ACTIVE IN THE KEY-ON
CONDITION WITH THE POSITIVE AND NEGATIVE
TERMINALS OF THE 12V SERVICE BATTERY
DISCONNECTED
