DOUBLE REAR WING DOORS
(for versions/markets, where provided)
The double rear swing doors fig. 66 are fitted with a
spring-loaded system that stops them when they
have opened to an angle of approximately 90
degrees.
To open them wider to an angle of 180 degrees, push
the locking device A fig. 67 (one on each side) as
shown in the diagram and simultaneously open the
doors.
WARNING
The spring-loaded system is designed for
optimum usage. Accidental knocks or a
strong gust of wind may release the springs,
forcing the doors to close.
Opening/closing the first swing door from the
outside
To open the door, turn the metallic insert of the key
in the lock or press button
on the remote
control and then pull handle A fig. 68 in the direction
of the arrow.
fig. 66
F0T0139
fig. 67
F0T0375
fig. 68
F0T0140
61
