FIBARO Motion Sensor User Manual

5
First launch
Open the casing by turning
the cover counter-clockwise
Step 1
Take off the cover
Step 2
Remove the battery blocker
and check if the battery
is placed correctly
Step 3
Close the cover by
turning it clockwise
Step 4
The device will blink red
it is ready to be paired
!
Fig. 1 Fig. 2
Fig. 3 Fig. 4
By default, the sensor stays
breached for 30 seconds
after detecting motion.
!

FIBARO Motion Sensor Specifications

General

Outdoor range	50m
Operating frequency	2400 MHz
Connectivity technology	Wireless
Battery type	CR123A
Battery voltage	3 V
Power source type	Battery
Number of batteries supported	1
Interface	Bluetooth
Certification	RoHS
Product color	White
Compatible products	HomeKit
Measuring parameters	Light, Motion, Temperature
Maximum operating distance	50 m
Brightness measurement range (inside)	0 - 32000 lx
Temperature measurement range (inside) (T-T)	0 - 40 °C

Weight and Dimensions

Diameter	46 mm
