EN 14
FDH 2001-E
Turn the setting knob for the chip depth (1) in a counter-clockwise direction to set a lower chip depth:
Lower chip depth
After finishing work, set the chip depth so that the knives are lowered and thus protected from damage. Turn the
setting knob for the chip depth to position “0” for this purpose.
5.2 Sawdust extraction (Fig. 5-6)
For an optimal sawdust extraction you can connect the supplied dust bag (2) to the hand-held electric planer.
To do so, slide the dust bag (2) into the the chip ejector (7) of the hand-held electric plane.
5.3 Parallel stop (Fig. 7/Item 13)
Use the parallel stop (13) when you want to planer parallel to the edge of the workpiece.
Fitting the parallel stop (Fig. 7)
Fasten the mount (d) of the parallel stop to the left side of the tool using the supplied thumb screw (a).
Now connect the mount (d) to the slide of the parallel stop (13).
The guide rail must always be aligned in downward direction.
Fix the distance required between the parallel stop and the edge of the workpiece.
Fasten the parts with the carriage bolt (b) and the wing nut (c).
6. OPERATION
6.1 ON/OFF switch (Fig. 8)
The hand-held electric planer comes with a safety switch which is designed to prevent accidents.
To switch on the tool press the side safety lockoff (3) and press the button switch.
Release the button switch (4) to switch off the electric plane. The button switch (4) jumps back into its
starting position.
6.2 Practical tips
Important: Only ever bring the hand-held electric planer towards the workpiece while switched on.
6.2.1 Planing surfaces
Now adjust the desired chip depth. Equip the front base plate and place the hand-held electric planer onto the
piece of wood you whish to plane. Then switch on the plane. Push to electric planer over the surface with both
hands and make sure that the both the front and the rear base plate lie flat on the workpiece.
Used a low chip depth for finishing surfaces and complete several passes over the surface.
