Machine description and package content
4. MACHINE DESCRIPTION AND
PACKAGE CONTENT
Machine Description (see Fig. 1.2)
Switch
Handle
Guiding handle
Bevel adjustment knob
Parallel guide adjustment knob
Parallel guide
Circular-saw blade guide
Circular-saw base
Blade stud
Cutting depth adjustment knob
Safety switch
Carbon brush cover
Allen wrench
1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -
10 -
11 -
12 -
13 -
Bevel angle measuring rod16 -
Package Content
Remove the machine carefully from the packaging and check the completeness of the following
parts:
Circular saw
Parallel guide
1 circular-saw blade
Warranty certificate
Operating instructions
Allen wrench
If some parts are missing or are damaged, please contact the vendor where you purchased the
machine.
