11
OPERATING INSTRUCTIONSIMPACT DRILL
EN
Adjustment and operation | Technical specifications
To loosen the screw, turn it in a clockwise direction.
The chuck can be equipped with all standard drills and extensions manufactured in
compliance with the business standards up to dia. XX mm.
The power tool is fitted with the quick-release chuck to facilitate exchange of the extensions
during manual drilling without a key.
Automated lock
The chuck can be equipped with all standard drills and extensions manufactured in
compliance with the business standards up to dia. 13 mm.
Amendments to text and technical parameters are reserved.
Changes in the text, design and technical specifi cations may change without prior notice
and we reserve the right to make these changes.keep it from turning as the drill bit rotates.
7. TECHNICAL SPECIFICATIONS
Power supply
Power input
Speed
Protection class
Maximum drilling capacity
Power supply cable length
Declared noise level
Vibration
230V~ / 50Hz
500W
0-3000 ot./min
II
dia. 13 mm
1.8 m
94dB(A)
ah.D1 = 2,25 ms
-2
– ah.D1 = 8,19 ms
-2
, K = 1,5 ms
-2
