Symbols | Machine description and package content
Use ear protection.
Wear work gloves.
Beware of falling branches.
3. MACHINE DESCRIPTION AND
PACKAGE CONTENT
Machine Description (see Fig. 1)
1.
2.
3.
4.
5.
6.
7.
8.
9.
Blade scabbard
Cutting blades
Protective shield
Motor
Head adjusting button
Connecting handle
Arresting element
Front handle
Arresting element
10.
11 .
12.
13.
14.
15.
16.
17.
18.
Locking bush
Rear handle
Grip area
Clamp
Shoulder strap
Safety lock
switches
Switch
Plug
