28EN Chain and guide maintenance | Specifications
Each cutting link must have equal length and edge bevels as shown. (fig. 37)
Cutting link length (4) (fig. 37)
File angle (5) (fig. 37)
Vertical bevel (6) (fig. 37)
Edge cutting angle (7) (fig. 37)
Chain guide
Turn the chain guide over from time to time to prevent unilateral wear.
The bar groove must be rectangular at all times. Check the bar groove for wear. To check,
apply a ruler to the bar and the outer edge of the cutting links. If there is a gap between them,
the bar is OK. Otherwise, the bar is worn. This means the bar needs a repair or a replacement.
(fig. 36).
Ruler (1) (fig. 36).
Gap (2) (fig. 36).
Zero gap (3) (fig. 36).
The chain tilts (4) (fig. 36).
13. SPECIFICATIONS
Chainsaw type: .....................................................................................................................................................4500
Weight (without guard and chain): ..........................................................................................................5.5 (Kg)
Dimensions (without guard and chain): ........................................................................410x235x265 (mm)
Fue: ........................................... Mixture (petrol 25: two-stroke oil 1) (manufacturer recommended oils)
Fuel tank capacity: ............................................................................................................................................550ml
Chain lubrication oil: .................................................... Engine oil SAE (manufacturer recommended oils)
Oil tank capacity: ...............................................................................................................................................260ml
Engine: ........................................................................................................................................................45,2 (cm3)
Maximum engine output power: .............................................................................................1,7 kw /7500rpm
Maximum engine speed with cutting accessories: ........................................................................10000rpm
Maximum engine speed at idle run: ......................................................................................................2800rpm
Maximum chain length: ....................................................................................................................................38cm
Gear wheel: ....................................................................................................................................................7Tx0.325
Chainsaw pitch: ...........................................................................................................................................0.325 (in)
Chainsaw inclination: ........................................................................................................................................0.058
Bar type: ................................................................................................................................................ Toothed chain
Bar dimensions: ..................................................................................................................................................18 (in)
Oil injection system: ........................................................................................... Automatic pump with adjuster
