PUSH REEL MOWER USER'S MANUAL
7
Explanation of instruction labels on the machine | Description | Supplied parts
2. EXPLANATION OF INSTRUCTION LABELS ON
THE MACHINE
Before putting into operation, please carefully
read the user's manual.
Attention, rotating blades! Protect yourself against
the danger of injury to limbs.
Always maintain a distance from moving parts.
Use hearing protection.
Use eye protection.
3. DESCRIPTION (FIG. 1)
1.
Push handle
2. Mowing reel
3. Wheel
4. Reel cover
5. Guiding cylinder
6. Grass catcher
4. SUPPLIED ITEMS (FIG. 2)
11 .
Push reel mower (ready to be assembled)
12. Top part of the push handle
13. Push handle extension poles (2 pieces)
14. Bottom part A of the push handle
15. Bottom part B of the push handle
16. Bolts M6 x 30 (8 pieces)
17. Hexagonal nut M6 (8 pieces)
