Fieldpiece ATWB1 User Manual

Relative Humidity (%RH)
Relative humidity is often found to help evaluate
air comfort or to find the target superheat of an air
conditioning system. There are a few ways to find
%RH. You can use an accessory head like the
ARH4 to measure %RH, wet bulb, dew point or dry
bulb directly. You could also use an actual sling psy-
chrometer, or use the ATWB1 wet bulb thermocou-
ple and a typical dry bulb thermocouple with the
chart to the left.
Relative Humidity (%RH)
Relative humidity is often found to help evaluate
air comfort or to find the target superheat of an air
conditioning system. There are a few ways to find
%RH. You can use an accessory head like the
ARH4 to measure %RH, wet bulb, dew point or dry
bulb directly. You could also use an actual sling psy-
chrometer, or use the ATWB1 wet bulb thermocou-
ple and a typical dry bulb thermocouple with the
chart to the left.
50 52 54 56 58 60 62 64 66 68 70 72 74 76
55 71 82 94
60 49 58 68 78 89 100
65 32 40 49 57 66 75 85 95
70 20 27 34 41 48 56 64 73 81 91 100
75 11 17 22 28 35 41 48 55 63 70 78 87 96
80 4 9 14 19 24 30 36 42 48 54 61 68 76 84
85 3 7 12 16 21 26 31 36 42 48 54 60 67
90 2 6 10 14 18 23 27 32 37 42 48 53
95 2 5 9 12 16 202428333742
100 2 5 8 11 151822252934
105 2 4 7 101316202327
110 2 4 7 9 12 15 18 21
115 2 4 6 9 11 14 16
Relative Humidity (%RH)
Dry Bulb Temperature (°F)
Wet Bulb Temperature °F
50 52 54 56 58 60 62 64 66 68 70 72 74 76
55 71 82 94
60 49 58 68 78 89 100
65 32 40 49 57 66 75 85 95
70 20 27 34 41 48 56 64 73 81 91 100
75 11 17 22 28 35 41 48 55 63 70 78 87 96
80 4 9 14 19 24 30 36 42 48 54 61 68 76 84
85 3 7 12 16 21 26 31 36 42 48 54 60 67
90 2 6 10 14 18 23 27 32 37 42 48 53
95 2 5 9 12 16 202428333742
100 2 5 8 11 151822252934
105 2 4 7 101316202327
110 2 4 7 9 12 15 18 21
115 2 4 6 9 11 14 16
Relative Humidity (%RH)
Dry Bulb Temperature (°F)
Wet Bulb Temperature °F
