SPECIFICATIONS
Display: 3¾ digit liquid crystal display (LCD) with a
maximum reading of 3999.
Analog bar graph: 41 segments with measure-
ments 20 times per second.
Range (RNG): Manual ranging mode (HS35)
Overrange: "OL" mark indication.
Auto power off: 30 minutes.
Operating environment: 32 to 122qF (0 to 50°C) at
<70% R.H.
Storage temperature: -4 to 140qF (-20 to 60°C), 0
to 80% R.H. with battery removed.
Accuracy: Specifications good in ambient condi-
tions of 73qF r9qF (23°C r5°C), <75% relative
humidity.
Temperature coefficient: 0.1u(specified accuracy)
per qF/°C. (32 to 64qF (0 to 18°C), 82 to 122qF(28
to 50°C)).
Power: Single standard 9-volt battery, NEDA 1604,
JIS 006P, IEC 6F22.
Battery life: 300 hours typical with alkaline.
Accessories: One pair test leads, one pair alligator
clips, k-type thermocouple, 9V battery (installed),
and operating instructions.
Safety: UL,CE,Cat III600V,UL61010-1,IEC/EN61010-1.
Temperature
Range: -30 to 1000qF (-34 to 538°C)
Resolution: 0.1qF/°C
Accuracy: r1qF, 32 to 120qF (0 to 49°C),
r1% + 1.5qF, -4 to 750qF (-20 to 399°C),
r2% + 4qF, -30 to -4qF (-34 to -20°C),
r2% + 4qF, 750 to 1000qF (399 to 538°C)
Sensor type: K-type thermocouple
Overload protection: 60 VDC or 30 VAC rms
Continuity
Audible indication: Less than 40:
Response time: 500ms
Green LED will be on continuously.
Overload protection: 500VDC or AC rms
DC volts
Ranges: 400mV, 4000mV, 40V, 400V, 600V
Resolution: 0.1mV
Accuracy: r(0.5% rdg + 2 dgt)
Input impedance: 3M: on V inputs, 10M: on mV
input
Overload protection: 600VDC or AC rms
Transient protection: 6kV for 10P sec
AC volts (50Hz - 500Hz)
Ranges: 400mV, 4V, 40V, 400V, 600V
Conversion: True RMS (HS36), average (HS35)
Crest factor: Less than or equal to 3 (HS36)
Resolution: 0.1mV
Accuracy:
r(1.2% rdg + 5 dgts) 50Hz ~ 60Hz on 400mV range
r(1.5% rdg + 5 dgts)
r(2% rdg + 5 dgts) on 600V range
Input impedance: 3M:
Overload protection: 600V DC or AC rms
Transient protection: 6kV for 10ȝ sec
DC current
Ranges: 400ȝA, 4000ȝA
Resolution: 0.1ȝA
Accuracy: r(1.0% rdg + 2 dgt)
Voltage burden: 1V, (8V on 4000ȝA range)
Overload protection: 500V DC or AC rms
Resistance
Ranges: 400:, 4k:, 40k:, 400k:, 4M:, 40M:
Resolution: 0.1:
Accuracy:
r(1.0% rdg + 4 dgts) on 400: to 400k: ranges
r(1.5% rdg + 4 dgts) on 4M: range
r(3.0% rdg + 5 dgts) on 40M: range
Open circuit volts: -0.45VDC typical, (-1.2VDC on
400: range)
Overload protection: 500VDC or AC rms
Capacitance
Range: 400ȝF
Resolution: 0.1ȝF
Accuracy: r(3% rdg + 5 dgts)
Overload protection: 500V DC or AC rms
Frequency
Ranges: 4k, 40k, 400k, 4M, 40MHz
Resolution: 1Hz
Accuracy: r(0.1% rdg + 3 dgts)
Sensitivity: 10Hz ~ 4MHz: > 1Vrms, 4MHz ~
40MHz: > 2Vrms, <5Vrms
Minimum pulse width: > 25ns
Duty cycle limits: > 30% and < 70%
Overload protection: 500VDC or AC rms
Voltage
Frequency
DC Current < 4000
ADC
Selecting Ranges
For DC voltage, set the meter to the VDC parame-
ter instead of VAC as shown above.
For all ranges choose a range just above the value
you expect. If display reads “OL” (overload), select a
higher range. If display shows less than three num-
bers, select a lower range for better resolution.
Resistance
Capacitance
Temperature
Works with Fieldpiece accessory
heads!
Connect to Fieldpiece accessory heads by simply
attaching them to the top of meter (1) or attach
remotely through leads (2). For most heads, move
dial to range shown (1). For the AAC clamp (ACH4),
move dial to VAC range (2).
Disconnect test
leads from volt-
age before plug-
ging in thermo-
couple!
Insure the tem-
perature being
measured is stable.
Maintain good con-
tact between the
thermocouple and
what's being meas-
ured.
CAT.III
300V
400A
CLAMP
ACH4
AC Current
Clamp
1AAC / 1mVAC
400AAC MAX
!
(1) (2)
WARNINGS
DISCONNECT AND UNPLUG TEST LEADS
before opening case.
TEST
NCV FUNCTION ON KNOWN LIVE
WIRE before using.
DO NOT
APPLY VOLTAGE greater than
30VAC or 60VDC to the thermocouple or the
jacks when the rotary dial is on OF.
REMOVE
THE THERMOCOUPLE when tak-
ing voltage measurements.
DISCONNECT
THE TEST LEADS when taking
temperature measurements.
DO NOT
APPLY VOLTAGE TO THE JACKS
when the rotary dial is on microamps. Even low
voltages can cause a current overload and blow
the fuse. Replace blown fuse to regain function.
