25. Custom button: Mark C5
26. Joystick compartment : Joystick can be disassembled and stored here (the joystick needs to be
taken out from here for the first use)
27. Spare battery: Spare battery increases the battery life of the remote control (spare battery is optional)
28. Custom button: mark C6
29. Custom DIP Switch: Mark C4
30. Roller: The default state can adjust the EV/ISO value of the camera, and can be customized for
third-party payload gimbal’s pitch or yaw control, marked with C8
The light is always on in normal state, and the light will flash when abnormal
Short press the power button when the power is off
1+Beep <10%, 1≤25%, 2≤50%, 3≤75%,4>75%, always on
Flashing slowly
4 lights are flashing in turn
Always on
Check the battery
Battery indicator
drone not connected
Remote control pairing or
software upgrade
Communication is normal
Function definition of remote control indicator lights (four white lights)
