4 Litre Air Cooler
Model No. COL1538
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts – Overview
1
2
3
4
5
6
7
8
9
10
1. Control Panel
2. Air Filter (Rear)
3. Cooling Pad (Rear)
4. Vertical Airflow Adjusters – adjust airflow vertically up and down
5. Air Intake
6. Air Outlet
7. Air Louvres – moves the airflow horizontally side to side
8. Water Tank (Rear)
9. Castors
10. Water Gauge
11. Ice Bottle (x2)
