CAUTION
This air-conditioner was designed for internal use.
- The air-conditioner must be installed vertically on
an even surface and on perfectly vertical walls.
(please refer to paragraph ‘Installation’) (Pag. 10)
- The connection to the mains must be carried out
according to the existing installation rules (please
refer to paragraph ‘Electrical Connection’) (Pag. 14).
- Make sure that curtains and/or other objects do not
obstruct the air intake filter and the internal air
delivery pipe, and that plants, shutters and blinds
do dot obstruct the external air intake.
- The air-conditioner must never be installed in
laundry rooms or in particularly damp rooms such
as greenhouses etc
- The air-conditioner must never be installed in
rooms containing explosive gases and/or
vapours or dangerous materials, or in rooms
where other machines generate high heat.
- Never place any object on top of the air-
conditioner
- Do not introduce any object in the internal and
external air outlets; this might cause injuries to
people and damage the machine.
- Do not switch on or off the air-conditioner by
plugging in or out the electrical plug into and from
the socket. This procedure, if frequently repeated,
might damage the cable, the plug or the socket,
which, in turn, might cause injuries to people. Use
always and only the remote control, and use the
protection switch device. (Please refer to ‘Electrical
connection’)
- Do not damage, pull, crush or fix with nails the
supply cable. When the supply cable is damaged,
please call the technical department.
- If you are not going to use the air-conditioner for
a long time, deactivate the protection switch device
and remove the plug from the socket.
- When installing the air-conditioner, mind that cool
air is not directly routed towards people.
- Do not install an oven where it may be directly
subject to the airflow from the air-conditioner, as
this may cause imperfect combustion
- We recommend ventilating periodically the room
where the air-conditioner is installed, especially if
the room is very crowded or if there are gas ovens
or smell sources.
- Do not use the air-conditioner for a long time with
open doors or windows; you will thus avoid
generating an excessive amount of condensate
water, in addition to achieving an energy saving.
- The ecologic cooling gas (R410A) used in the air-
conditioner has null oxygen depauperization
properties (ODP=0). In spite of that, the air-
conditioner must be disposed of in the proper
disposal centres.
INSTALLATION
How to install it
To successfully install it and to have optimal
operating performances, follow carefully the
instructions contained in this manual.
Non-compliance with installation procedures may
cause the air-conditioner not to work properly and
relieves Fimer Air Conditioning from any warranty
duty and from any responsibility in case of
damages to people, animals or objects.
Where to install it
The air-conditioner must be installed according to
the specifications detailed below:
- Only install the air-conditioner on an outer wal
- The wall must be sufficiently strong to support th
e
weight of the unit and to guarantee an adequate
fixing.
- Leave enough room around the unit for
maintenance interventions (as indicated in the
picture 1).
- If you install it in a low position: minimum distance
from the floor: 300 mm.
If you install it in a high position: minimum distance
from the ceiling: 150 mm
- There must never be obstacles (such as plants,
flower-pots, thick gratings etc.) to the free
circulation of the air from the coaxial pipe and from
the air delivery pipe (please refer to the
picture 2), as this might
jeopardize the proper operation
of the air-conditioner.
- Please make sure that, where
you intend to drill the hole for
the coaxial pipe, there are
neither electric cables, water
pipes, installations etc., which
might be damaged, nor pillars
and beams, as the drilling of
the hole would become
extremely difficult.
Fig. 1
Fig. 2
