Document #50049 Rev. E0 01/22/01 P/N 50049:E0
39
Programming Options
Ademco Contact ID Format
If 'E' is entered for address 42, the following data is automatically programmed for the Secondary phone number
event codes. Enter '000' for the data setting to disable the report.
Notes:
1.
Zero entries prevent the transmission of the report to the Central Station
2.
Refer to Contact ID program locations 64 - 68
3.
The identification of the zone/sensor number is automatically transmitted by the UDACT-F and is added to the
main event code. Refer to Table A-3, “Ademco Contact ID Reporting Structure,” on page 49, for additional
information
4.
Factory default for this report is 110 (110 is transmitted for modules, however, 111 will automatically be trans-
mitted for smoke detectors). Use Type Mode (refer to “Type Mode” on page 44) to change this report per zone
or point
TABLE 3-7: Ademco Contact ID Secondary Number
Address Description Setting
1
Sensor Number
139 - 141 Secondary # General Alarm Code 110
000
2
142 - 144 Secondary # Zone/Point Alarm Code
110
4
Note
3
145 - 147 Secondary # General Supervisory Code 200
000
2
148 - 150 Secondary # Zone/Point Supervisory Code 200
Note
3
151 - 153 Secondary # General Fault Code 300
154 - 156 Secondary # AC Fault Code 301
157 - 159 Secondary # Zone/Point Fault Code 380
Note
3
160 - 162 Secondary # Low Battery Fault Code 302
163 - 165 Secondary # Telco Primary Line Fault Code 351
166 - 168 Secondary # Telco Secondary Line Fault Code 352
169 - 171 Secondary # NAC Fault Code 321
172 - 174 Secondary # Communication Trouble Primary # Code 354
175 - 177 Secondary # Communication Trouble Secondary # Code 354
178 - 180 Secondary # 485 Communication Trouble Code 300
181 - 183 Secondary # System Off Normal Code 308
184 - 186 Secondary # UDACT-D Off Normal Code 350
187 - 189 Secondary # System 24 Hour Test 602
190 - 192 Secondary # System 24 Hour Test with Active Event 608
193 - 195 Secondary # Manual Test Message 601
To Next Page
