Error Messages
14
* LED flash
Lo – Low Tone
Hi – High Tone
Beep / Flash Sequence What it means What to do
During Power up
LoHi-LoHi-LoHi Indicates Battery Lift is open No action required
during power up
Long Tone Indicates start of power up test No action required
Lo – Lo – Lo No Dip Switch has been selected No action required
Hi – Lo – Lo Dip Switch 1 has been selected No action required
Lo – Hi – Lo Dip Switch 2 has been selected No action required
Hi – Hi – Lo Dip Switches 1 and 2 No action required
have been selected
Lo – Lo – Hi Dip Switch 3 has been selected No action required
Hi – Lo – Hi Dip Switches 1 and 3 No action required
have been selected
Lo – Hi – Hi Dip Switches 2 and 3 No action required
have been selected
Hi – Hi – Hi Dip Switches 1, 2 and 3 No action required
have been selected
Dip Switch 4 has no function and
will not affect beep sequence
During standard operation
*---(32secs)---*---(32secs)---*---(32secs)---*---etc. LED indicates that the system is No action required
working properly
*-(1.3secs)-*-(1.3secs)-*-(1.3secs)-*-(1.3secs)-*-etc LED indicates that the Dorgard If no alarm is sounding
is “hearing” a possible alarm (or a please refer to the
continuous background noise section on adjusting
in excess of 65
decibels
) the sensitivity of
Dorgard.
HiLo – HiLo – HiLo – HiLo – HiLo – HiLo – HiLo – HiLo Dorgard is about to release door No action required
*-------*-------*-------*-------*-------*-------*-------* (If warning tone has been
disabled – then no tone will sound)
