Outdoor Thermocouple Flame Sense (TFS)
Linear Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
INSTALLATION PRECAUTION:
This re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
MODELS
Natural Gas Description Propane
FPB-24LTFS-N
24” Linear Pan & Burner
FPB-24LTFS-P
FPB-30LTFS-N
30” Linear Pan & Burner
FPB-30LTFS-P
FPB-36LTFS-N
36” Linear Pan & Burner
FPB-36LTFS-P
MH# 60069

Table of Contents

Questions and Answers

  • E
    Edwin NelsonAug 14, 2025
    Why won't the remote work on my Firegear FPB-24LTFS-N?
    • M
      Mary HayesAug 14, 2025
      If the wireless remote transmitter won't operate your Firegear Outdoor Fireplace: * Ensure the transmitter is within 25 feet of the control module. * Check that the batteries in the transmitter or battery pack are fully charged and correctly installed. * If using an AC adapter, ensure its leads are securely connected to the “POWER” connection on the control module. * Confirm the “Remote/Off” switch on the control module is set to “Remote.” * Ensure the control module has learned the transmitter’s security code (refer to the learning section on page 8). * Avoid placing the remote transmitter on a metal surface or near large metal obstructions, as this can reduce its operating range.
  • A
    Ann ThomasAug 25, 2025
    What to do if my Firegear FPB-24LTFS-N Outdoor Fireplace has sensor safety issues?
    • V
      valeriearellanoAug 25, 2025
      To address sensor safety issues with your Firegear Outdoor Fireplace: * Press the OFF and then ON buttons to re-attempt normal ignition. * Allow the thermocouple to cool for at least 30 seconds. * Check if a flame is present when the valve is turned OFF; if so, replace the valve. * Ensure the ground wire from the thermocouple and module are connected to the gas valve. * If the 3-probe ignitor is exposed to excessive moisture, allow it 24-48 hours to dry out.
  • D
    Devin NicholsAug 29, 2025
    What causes overheating in my Firegear FPB-24LTFS-N?
    • S
      Shannon HarrisAug 29, 2025
      To address thermal safety (overheat protection) issues with your Firegear Outdoor Fireplace: * Allow the module’s internal temperature to cool below 160°F, then press the ON button. * Ensure proper ventilation to the control module. * Check if the module (inside the valve box) is located in an unapproved location, too close to the burner, and move it to a cooler location if necessary.
  • C
    chase47Sep 2, 2025
    Why is flame modulation not working on my Firegear FPB-24LTFS-N Outdoor Fireplace?
    • C
      Corey BenitezSep 3, 2025
      To solve flame modulation issues with your Firegear Outdoor Fireplace: * Ensure the black and red leads from the battery pack are securely connected to the red and black leads from the Hi/Lo latching solenoid on the valve body. * Verify the selector switch on the battery pack is set to LATCHING SOLENOID only. * Check functionality with all transmitters to determine if the issue is with the main control system or an individual transmitter.
  • S
    shurstSep 10, 2025
    What to do if ignitor sparks frequently on my Firegear Outdoor Fireplace?
    • S
      Sophia CisnerosSep 12, 2025
      If the ignitor sparks frequently at the pilot hood during operation of your Firegear Outdoor Fireplace, the control module is generating a spark because the system is in the ON position but the pilot does not light. This could be because the thermocouple may not be hot enough or generating enough millivolts. To resolve this: * Ensure the tip of the thermocouple is clean. * Make sure that wind does not blow the pilot flame out.
  • S
    Sandra MillerNov 8, 2025
    How to fix ignition safety issues with my Firegear FPB-24LTFS-N?
    • M
      Melissa SerranoNov 8, 2025
      To resolve ignition safety issues with your Firegear Outdoor Fireplace: * Try pressing the OFF and then ON buttons to re-attempt ignition. * Ensure the gas supply is turned ON. * Make sure the gas line is purged of air and free from blockages. * Confirm the flame properly contacts the thermocouple on the pilot assembly and clean any soot buildup. * Verify the orange/white leads from the module are connected to the “PILOT” connection, and the green/white leads are connected to the “MAIN” connection on the valve body. * Check that the lead from the pilot assembly is connected to the 'I' terminal on the module. * Verify the lead from the flame sensor on the electrode assembly is connected to the 'S' terminal on the module, and the ground terminal is connected to ground. * Ens...
