FirePro FP-20SE User Manual

FirePro
FirePro Systems
REV. BYDATEDESCRIPTION
Aerosol Generator FP-20SE/T/TH
1.0 Generator Installation guide line 24/06/2016 Michaelides Loucas
D
C
B
A
4 3 2 1
D
C
B
A
4 3 2 1
32mm Diameter
U-Type Metal
Bracket
FirePro
Front View
Side View
Bottom View
Step 5
The aerosol generator is ready for cable connections.
Step 4
Pass the screws through the aligned holes and fix them on the surface material.
Step 3
Select type of screws suitable to the surface material to be fixed (these screws are
not supplied with the kit).
Step 2
Align “Bracket” holes with surface material holes.
Step 1
Take the “Bracket” and place it on the aerosol generator.
Page 2
