Firex LWD-3 - 5: Figures and Details; Size of Appliance and Position of Connections

Instruction manual for installation, maintenance and use
Vegetables Washer
LWD-GB-02
Pagina 18 di 20
5: FIGURES AND DETAILS
5.1. Size of appliance and position of connections
E = POWER CABLE ENTRANCE 400V 3N+T
B = COLD WATER INLET 3/4"
S = OUTLET ø40 (WITH FLOOR DRAIN TRAP 300x300 mm)
