CONNECTORS
Multipole Low Voltage
Cable Assembly Instructions
Type
Contact Termination
Cable Clamp
1)
Number of Contacts
L
C
B
Part Number
Crimping Tool
Part Number
Positioner
Part Number
Insertion Tool
Part Number
Extraction Tool
Wrench Size
Wrench Size
Torque
[Nm]
Plug Receptacle Plug Receptacle
Type "A" Type "Z"
LBC
102
A
051
Z
Solder
S 2 7 2.5 2 7 7 0.6
U 2 7–2 770.6
E 2 5 2.0 2 7 7 0.6
102
A
052
Z
Solder
S 3 7 2.5 2 7 7 0.6
U 3 7–2 770.6
E 3 522 770.6
102
A
053
Z
Solder
S 4 7 2.5 2 7 7 0.6
U 4 7–2 770.6
E 4 522 770.6
Crimp
U 4 9 – 3 TX00.240
2)
TX00.210 TX00.200 7 7 0.6
1
2
102 Series
1)
S -
Shielded cable clamp
U - Unshielded cable clamp
E - Sealed cable clamp
2)
See Online Crimping Instructions
All specifications are typical and have to be adjusted according to the cable construction and dimensions.
Torque [Nm] are recommended values that may be influenced by the characteristics of the cable jacket.
Tests have to be made to evaluate the exact values. To secure the cable clamp nut, we recommend
the use of thread locking adhesive.
All dimensions are in millimeters and are for reference only.
