Product dimensions
WH8560F
WH8560P
WH8560J
WH8060F
WH8060P
WH7560P
WH7560J
PRODUCT DIMENSIONS mm mm mm
A
Overall height of product 850 850 850
B
Overall width of product 600 600 600
C
Overall depth of product
(including dial and door
whenclosed)
645 645 590
D
Depth of door open 1065 1065 1010
E
Minimum door clearance to
adjacent wall
330 330 330
Standpipe height min. 800–1200 min. 800–1200 min. 800–1200
MAXIMUM CAPACITY kg kg kg
8.5 8.0 7.5
Note: the exact height of your washer is dependent on how far the feet are extended
from the base of the machine. The space where you install your washer needs to be at
least 40mm wider and 20mm deeper than its dimensions.
Electrical supply: 220–240V, 50Hz Sinusoidal, minimum 10A.
Inlet water static pressure: Max. 1MPa (150psi), Min. 30kPa (4.5psi).
Inlet water flow rate at tap: Min. 6litres/min.
E
D
