Fisher MC-620 - Page 14

Ret.
rt No.
No. Pa lo
P.C.BOARD PARTS LIST (continued)
Description Q’
<
SW601 620 015 1917
SwW602 620 015 1917
SW603 620 015 1917
SW604 620 015 1917
SW605 620 015 1917
Keyboard Switch 6 mm (Up)
Keyboard Switch 6 mm (Down)
Keyboard Switch 6 mm (FM)
Keyboard Switch 6 mm (AM)
Keyboard Switch 6 mm (MANUAL/AUTO)
MEMORY SWITCH P.C.B. ASSY
55 620 080 7432
SW606 620 015 1917
Sw607 620 015 1917
SwW608 620 015 1917
SW609 620 015 1917
SW610 620015 1917
SW611 620 015 1917
Memory Switch P.C.B. Assy
Keyboard Switch 6 mm (M1)
Keyboard Switch 6 mm (M2)
Keyboard Switch 6 mm (M3)
Keyboard Switch 6 mm (M4)
Keyboard Switch 6 mm (M5)
Keyboard Switch 6 mm (M6)
BEAT SWITCH P.C.B. ASSY
56 620 080 7449
SW304 620 015 3508
LAMP P.C.B. ASSY
57 620 080 7456
620 030 8151
620 052 0171
AUX P.C.B. ASSY
58 620 080 7463
620 020 4736
JACK P.C.B. ASSY
59 620 080 7487
620 017 8228
401 007 0107
401 007 0107
R291
R292
Beat Switch P.C.B. Assy
Slide Switch 2P2T (Beat SW.)
Lamp P.C.B. Assy
Lamp
Spacer
AUX P.C.B. Assy
Pin Jack 2P (AUX)
Jack P.C.B. Assy
Jack 7P Black (Phones)
CARBON 100 JA 1/2W
CARBON 100 JA 1/2W
LOOP ANTENNA TERMINAL P.C.B. ASSY
60 620 080 7494
FUSE P.C.B. ASSY
61 620 187 5126
620 017 2738
AN 423.006 1701
AC IN P.C.B. ASSY
62 620 187 5140
620 022 2587
620 031 4763
Loop Antenna Terminal P.C.B. Assy
Fuse P.C.B. Assy
Fuse Clip
FUSE 250V 2A
AC In P.C.B. Assy
EC Terminal 1P
Wire Wrap Terminal
POWER SWITCH P.C.B. ASSY
63 620 187 7243
620 053 6899
A 620 015 2341
C261 A\ 620 006 6679
Power Switch P.C.B. Assy
Cover Safety
Switch Push Power
Capacitor 0.01MF400V
TRANSISTOR 12V P.C.B. ASSY
64 620 187 7250
Q206 405 035 7602
Transistor 12V P.C.B. Assy
TR KSD288-Y
TRANSISTOR 11V P.C.B. ASSY
65 620 187 7267
Q211 405 035 7602
SPEAKER P.C.B. ASSY
66 620 080 7470
620 020 4736
PC502 620 024 3070
NOTES:
Transistor 11V P.C.B. Assy
TR KSD288-Y
Speaker P.C.B. Assy
Pin Jack 2P (Speakers)
Wire 3 Parallel
a ott
Se Sb Se ek
won —
a oo
1. Parts order must contain Model Number, Part Number and De-
scription.
2. Ordering quantity of screws and resistors must be multiple of 10
pcs.
—-14—
