Fisher MC-723BK User Manual

6. Press the appropriate PLAY button (Deck A or B). Tape
playback will begin.
7. Adjust the VOLUME, BALANCE and GRAPHIC EQUAL¬
IZER controls for the most pleasant listening level and
tone balance.
8. To stop playback temporarily, press the PAUSE button.
To restart, release the PAUSE button by pressing it again.
9. When playback is finished, press the STOP/EJECT button.
If the end of the tape is reached (while playing back),
your tape deck will stop automatically.
10. T o switch off the unit, release the POWER button.
CONTINUOUS PLAYBACK
This unit allows the use of both tape decks to play back tapes
successively. In the continuous playback mode, the unit plays
a tape on DECK B, then automatically switches to DECK A to
play back a second tape.
1. Switch on the unit’s power,
2. Press the TAPE FUNCTION switch.
3. Set the RECORD/PLAY switch to CONT. BOA (right).
4. Press both STOP/EJECT buttons and insert recorded
cassettes into both decks.
5. Set the DOLBY NR switch for the cassette tape in DECK B.
NOTE:
When the unit switches from DECK B to DECK A, the
previous condition of the DOLBY NR system (DOLBY
NR ON or OFF) will come into effect for DECK A.
To play back tapes successively, we recommend the use of
tapes that have been recorded under the same conditions
(recorded with the Dolby NR system, or without the Dolby
NR system).
6. First, press the PLAY button on DECK B, press the PAUSE
button on DECK A. then press the PLAY button on DECK
A. The unit will begin to play using DECK B.
7. Adjust the VOLUME, BALANCE and GRAPHIC EQUAL¬
IZER controls for the most pleasant listening level and
tone balance,
8. When the end of the tape in DECK B is reached, the PAUSE
button on DECK A will automatically release and DECK A
will start playing.
Reset the DOLBY NR switch if necessary,
9. When the end of the tape in DECK A is reached, DECK A
will stop automatically.
If you wish to resume the continuous playback, replace the
cassettes (if desired), reset DECK B to the playback mode,
press the PAUSE button on DECK A, then press the PLAY
button on DECK A.
FAST FORWARD/REWIND {Decks A and B)
To play any desired portion in the middle of a tape, press the
Fast Forward button. Press the STOP/EJECT button when the
desired playback section is reached.
To return the tape to the beginning, press the Rewind button.
Press the STOP/EJECT button to stop the tape.
TAPE RECORDING {Deck B Only)
1. Switch on the unit's power.
2. Select the desired sound source with the FUNCTION
switches (AM, FM, FM STEREO, PHONO, or AUX).
3. Press the STOP/EJECT button and put a cassette into the
compartment, with the side to be recorded toward you
and the tape slot at the bottom.
4. Set the RECORD/PLAY switch to SOURCE (right).
5. Set the DOLBY NR switch as desired.
To record with the Dolby B-type NR system, set the
switch to ON (left).
To record without the Dolby NR system, set it to OFF
(right).
6. Set the TAPE COUNTER to 000 by pressing the TAPE
COUNTER Reset button.
7. First, press the PAUSE button, then press the RECORD
button.
8. Adjust the INPUT LEVEL control, so that the lights in
the PEAK level meter do not light beyond 0, even at the
highest input level.
RECORD
|| |SB " =
PtAK LEVEL dB . IS -7 -) o +3 UR
. . .nnlimut umiUmiIhI
Li- —
Correct Range
RECORD
WAK iruri 06 15 / -3 0 *3 OB
Nil . . . . . . .
" "
...
I-—4
Overload
Fig. 9
NOTE:
Be sure that your recording level is set correctly.
Recording with the level set too high will give you distorted
recordings.
Recording with the level too low (the lights in the meter
illuminate only slightly, or not at all) will give you low
volume and too much noise during playback.
9. A fter setting the proper recording levels, start recording
by pressing the PAUSE button again.
During recording, the RECORD indicator will light, (f
you wish to stop the tape briefly without resetting the
RECORD button, press the PAUSE button. To restart,
press the PAUSE button again.
10. To stop recording completely, press the STOP/EJECT
button. If the tape winds completely onto the right-hand
reel while recording, the tape deck will stop automatically.
11. To switch off the unit, release the POWER button.
-9 -
