1. The “X” button lets you go back to the previous
screen (iOS device only).
2. This indicates the water depth.
3. This indicates the water temperature.
4. This shows the battery life of the sonar.
5. Clicking on this button allows you to adjust
recording, depth, sounds, left scale/right scale, raw
data/fishview mode, battery life indicator, bottom
display, and unit of measurement settings.
6. The “Take Photo” option allows you to take a
screenshot of the sonar data on the screen.
7. The “Drop Pin” button allows you to drop a pin on
the map.
8. The “ON” button indicates that the sonar has been
turned on. Click on it to turn it off.
9. The fish symbol means that there could
potentially be a fish in the indicated area.
10. This area indicates the mapped bottom of the
water body.
11. This ruler helps you determine the depth of each
fish.
