8
User’s Guide
Tuner Display
Blend
Use the Blend slider to set the balance between the pickup and the
Acoustic Sound Image. Lower the slider to emphasize the pickup.
Move it up to hear more Acoustic Sound Image. Set the Blend slider
to the center detent for an even balance of both.
Tone Controls
The Bass, Mid and Treble controls can be set independently for both
the pickup and the Sound Images.
Flashes when the note is below
pitch. Also denotes negative
polarity when the pickup phase
parameter is engaged.
Lights up when
note is in tune.
Flashes when the note is
above pitch.
Lights up when tuner is on.
Lights up when the
note is raised 1/2 step.
Flashes when
Anti-Feedback
filter is ready
to measure
feedback.
Flashes when
battery is low.
A B C D E F G #
p
q
•
•
