3.
Installation Instructions
When installing, simply fix all screws first, then tighten the screws when the installation of
frame is done.
1. Put the machine flat on the ground and stand the columns and flip the console with the direction
shown in the picture below.
2. Remove the preinstalled screws M8*22. Use 5# hexagon wrench and screw M6*12 to lock and
fix the base(two screws for each side). Then install the screw M8*22 back.
3. Hold left& right columns, use 6# hexagon wrench and screw M8*25 to lock the console frame
on the columns(Tighten all screws in above steps, and please notice not to clamp the cable by
column).
