3. Tighten the bolts when you have completed the adjustments. Rotate the wheel
to check that the brakes do not rub. The correct torque for the brake calliper is
6-8 Nm
3.6.2 Adjusting mechanical disc brakes (200 series Ava/Ranger and Agile/Flow
from the years 21-22)
1. Loosen or tighten the adjustment ring at the connection point of the brake
cable at the end of the brake lever. In this way, the gap of the brake pads can
be slightly adjusted. If this is not suicient to reach a suitable gap, carry out the
following measures:
