FiveO D 10A - Technical Specifications - D 8 A;D 10 A; D 8 A Specifications; D 10 A Specifications

!
!
Model Active
D 8A
System Type
2-Way 8” Active Vented Speaker Cabinet
Program Power Low/High
200W Bi-AMP (Low 150W+High 50W-Class AB)
Peak Power Low/High
400W Bi-AMP (Low 300W+High 100W-Class AB)
Transducer Low
8”Woofer -1.5” Voice Coil. with ventilation
Transducer Driver
1” High Definition Neodymium Driver
Maximum SPL@1m
113dB Max (Calculated)
Input Sensitivity
-7dBu
Crossover Frequency
3kHz
Frequency Response
70Hz - 20kHZ (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
Input Connectors
COMBO - LINE IN / XLR - LINK
External Connectors
Volume Control / Power on with Green LED / Clip Limiter / Red LED /
Ground Lift
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Metal grille. ABS Cabinet with rubber foot
Dimension (H x W x D)
16.1”(410mm) x 10.6”(268mm) x 10.2”(260mm)
Net weight
7.8kg / 17.2lbs
Volume
1.67 CFT
Model Active
D 10A
System Type
2-Way 10” Active Vented Speaker Cabinet
Program Power Low/High
250W Bi-AMP (low 200W-Class D; High 50W-Class AB)
Peak Power Low/High
500W Bi-AMP (Low 400W-Class D; High 100W-Class AB)
Transducer Low
10”Woofer -2” Voice Coil. with ventilation
Transducer Driver
1” High Definition Neodymium Driver
Maximum SPL@1m
120dB Max (Calculated)
Input Sensitivity
0dBu
Crossover Frequency
2.5kHz
Frequency Response
65Hz - 20kHZ (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
Input Connectors
COMBO - LINE IN / XLR - LINK
External Connectors
Volume Control / Power on with Green LED / Clip Limiter / Red LED /
Ground Lift
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Metal grille. ABS Cabinet with rubber foot
Dimension (H x W x D)
20.5”(521mm) x 13.4”(342mm) x 12.2”(310mm)
Net weight
10.1kg / 22.3lbs
Volume
2.94 CFT
