FiveO D 10A - Technical Specifications - D 12 A;D 15 A; D 12 A Specifications; D 15 A Specifications

!
!
Model Active
D 12A
System Type
2-Way 12” Active Vented Speaker Cabinet
Program Power Low/High
500W Bi-AMP (low 400W-Class D; High 100W-Class AB)
Peak Power Low/High
1000W Bi-AMP (Low 800W-Class D; High 200W-Class AB)
Transducer Low
12”Woofer -2” Voice Coil. with ventilation
Transducer Driver
1”Exit Driver - 1.4” Compression Driver
Maximum SPL@1m
122dB Max (Calculated)
Input Sensitivity
0dBu
Crossover Frequency
1.8kHz
Frequency Response
60Hz - 20kHZ (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
USB Player (optional)
With USB&Mirco SD CARD, Bluetooth
Input Connectors
INPUT1-Mic With XLR*1&6.3 Jack*1 / INPUT2-Line With
XLR*1&6.3Jack*1&3.5Jack*1
External Connectors
Input 1&2 and Master Volume Control / 2 Band EQ-High&Low / Power
ON with Green LED / Clip Limiter with Red LED / Ground Lift / DSP
Presets
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Metal grille. ABS Cabinet with rubber foot
Dimension (H x W x D)
24.3”(618mm) x 16.9”(430mm) x 13.8”(350mm)
Net weight
17.1kg / 37.7lbs
Volume
4.53 CFT
Model Active
D 15A
System Type
2-Way 15” Active Vented Speaker Cabinet
Program Power Low/High
500W Bi-AMP (low 400W-Class D; High 100W-Class AB)
Peak Power Low/High
1000W Bi-AMP (Low 800W-Class D; High 200W-Class AB)
Transducer Low
15”Woofer -2” Voice Coil. with ventilation
Transducer Driver
1”Exit Driver - 1.4” Compression Driver
Maximum SPL@1m
123dB Max (Calculated)
Input Sensitivity
-6dBu
Crossover Frequency
2.2kHz
Frequency Response
50Hz - 20kHZ (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
USB Player (optional)
With USB&Mirco SD CARD, Bluetooth
Input Connectors
INPUT1-Mic With XLR*1&6.3 Jack*1 / INPUT2-Line With
XLR*1&6.3Jack*1&3.5Jack*1
External Connectors
Input 1&2 and Master Volume Control / 2 Band EQ-High&Low / Power
ON with Green LED / Clip Limiter with Red LED / Ground Lift / DSP
Presets
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Metal grille. ABS Cabinet with rubber foot
Dimension (H x W x D)
27.6”(700mm) x 18.9”(480mm) x 15”(380mm)
Net weight
19kg / 41.9lbs
Volume
6.45 CFT
