FiveO D 10A - Technical Specifications - Subwoofers; D 12 A SUB Specifications; D 15 A SUB Specifications

!
!
Model Active
D 12A SUB
System Type
12” Active Subwoofer Speaker Cabinet
Program Power
600W
Peak Power
1200W
Transducer Low
12”Woofer -3” Voice Coil. with ventilation
Maximum SPL@1m
123dB Max (Calculated)
Input Level
L-R LINE Input -20dBu
Active Crossover
HPF 80Hz Under Analog Processor
Frequency Response
45Hz - 160Hz (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
Input Connectors
L-R(COMBO/XLR-F) / L-R LINK(2-XLR-M) / L-R Output (2-XLR-M)
Balanced(15k Ohms)
External Connectors
Volume Control / Power on with Green LED / Clip Limiter / Red LED /
Ground Lift / Ground Lift / Phase Switch / HPF 80Hz Bypass
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Painted MDF Cabinet, Black Metal Grille Protection
Dimension (H x W x D)
17.7”(450mm) x 16.9”(430mm) x 18.11”(460mm)
Net weight
24.3kg / 53.6lbs
Volume
5.81 CFT
Model Active
D 15A SUB
System Type
15” Active Subwoofer Speaker Cabinet
Program Power
600W
Peak Power
1200W
Transducer Low
15”Woofer -3” Voice Coil. with ventilation
Maximum SPL@1m
124dB Max (Calculated)
Input Level
L-R LINE Input -17dBu
Active Crossover
HPF 80Hz Under Analog Processor
Frequency Response
40Hz - 150Hz (-10dB)
Protection
Over heat Protection / Short Circuit Protection / Compressor
Input Connectors
L-R(COMBO/XLR-F) / L-R LINK(2-XLR-M) / L-R Output (2-XLR-M)
Balanced(15k Ohms)
External Connectors
Volume Control / Power on with Green LED / Clip Limiter / Red LED /
Ground Lift / Ground Lift / Phase Switch / HPF 80Hz Bypass
Power Supply
110-120V~50/60Hz or 220-240V~50/60Hz Switchable
Enclosure
Painted MDF Cabinet, Black Metal Grille Protection
Dimension (H x W x D)
20.5”(520mm) x 18.9”(480mm) x 22.2”(564mm)
Net weight
29.3kg/64.6lbs
Volume
8.78 CFT
