SOLDERING STATION AP 2 MODEL: 51091
ATTENTION! Please read the user manualcompletely and carefully. It is part of the
product and includes important information for proper installation and use. Keep
this guide to have it available, when there are uncertainties, or the product will be
passed on.
Content: Page:
1 Description and Function 10
2 Intended Use 10
3 Notes on Safety 11
4 Parts Package 12
5 Operating- and Adjusting Elements, Connecting 12
6 Operating 13
6.1 Preparing 13
6.2 Connecting 13
6.3 Adjusting the Temperature 13
6.4 Handling 13
6.5 Notes on Application 14
7 Care, Maintenance, Storage and Transport 15
8 Troubleshooting 15
9 Warranty and Liability 15
10 Specications 16
11 Notes on Waste Disposal 16
12 CE-Declaration 16
1 Description and Function:
The Soldering Station AP 2 is made for using in hobby-electronics, production and
workshops. It comes with soldering iron, stand for the soldering iron with sponge tray and
viscose-cleaning sponge, as well as an analog temperature adjustment. A compact, stabile
and protective-insulated housing is included. The high-power 40 - 48 Watts soldering iron
heats up quickly and is driven by safety-low voltage. Stepless adjusting is possible between
150-450°C.
2 Intended Use:
Your product is made for soft-soldering uses in housholds only. It means you may only use it
for soldering / unsoldering of electric and electronic components in printed circuits and
modules, for tin coating of conductor paths and cable ends as well as making cable
connections. Another use is not allowed.
Use the product only in dry interior rooms. If not attending to these regulations and notes on
safety, it might causes fatal accidents, injuries and damages to persons and property. Never
use this product for heating up liquids, such as water, bases, solvents, etc. or plastic parts
because of producing toxic smoke and there is a danger of burning!
