INSTALLATION AND ASSEMBLY
3
5
NOTICE
ALWAYS make sure the unit is unplugged before beginning assembly! NEVER
move or clean the heater, or change the bulb, while it is plugged in.
NOTICE
ALWAYS attach the feet before using! NEVER plug in or operate this unit if the feet
are not securely attached!
STEP1: Carefully turn the Stove Heater(A) upside down and lay it on a clean soft surface.
STEP2: Align the holes in the Leg(B) with the holes in the corner of the stove frame as shown.
STEP3: Thread four M4x12mm Screws(C) through the holes in the leg and into the stove frame.
STEP4: Partially tighten the screws with a phillips screwdriver. Repeat Step 2 and 3 for the other
three Legs(B).
STEP5: Check the alignment and tighten all.
Stove Heater (A)
Legs(B)
M4x12mm Screws(C)
