PRODUCT INFORMATION
INSTALATION
Voltage:
AC 100~240V 50/60Hz
Power: 250W
Lamp beads: 864 pcs 5050
RGB LEDs + 96 pcs white LEDs
Control mode: DMX 512,
self-propelled, master-slave,
Sound controll
Channel: 4/11/32/39
Dimming: 32 bit,
0~100 linear dimming
Features: 8+8 secons
running + wash + ash
Operang temperature:
-30°C ~ 50°C
Stroboscopic frequency: 1~30 Hz
Housing: Metal, Black
Connecon mode: DMX512,
PowerCON IN/OUT,
DMX 3-pin IN/OUT
IP grade: IP20
Height [cm]: 24,5
(with packaging 31,5)
Width [cm]: 45
(with packaging 49)
Depth [cm]:
9 (with packaging 17)
Weight [kg]: 3,6
Weight with packaging [kg]: 4,6
Type of packaging: Carton Box
The unit should be mounted via
its screw holes on the bracket.
Always ensure that the unit is
firmly fixed to avoid vibration
and slipping while operating.
Always ensure that the structu-
re to which you are attaching
the unit is secure and is able
to support a weight of 10 ti-
mes of the unit’s weight. Also
always use a safety cable that
can hold 12 times of the we-
ight of the unit when installing
the fixture. The equipment must
4
be fixed by professionals. And it
must be fixed at a place where is
out of the touch of people and
has no one pass by or under it.
The fixture may be installed in
any orientation, but if installed
horizontally with a downward
beam-angle, water can poten-
tially pool in the fan wells. Under
normal operation the moisture
will evaporate. However, in loca-
tions with high rainfall, you may
wish to fabricate a rain shield
above the fixture, or modify the
