6. Mode
 DMX Control
 Sound
 Auto
7. Resume default
8. Reserve
11. DMX PROTOCOL ：
Channel
Function
DMX
Value
Feature
Note
16
Bit
8
Bit
1
1
Strobe
000-009
Full off
010-049
Full on
050-089
Strobe from slow to fast
090-129
Pulse effect opening, increasing
130-169
Pulse effect closing, increasing
170-209
Random strobe with decreasing speed
210-255
Full on
2
2
Dimmer
000-255
Dimming from 0-100%
3
3
Reset/
shutter off
000-099
No function
100-105
Lamp off (3s)
106-199
No function
200-205
Lamp on
206-249
No function
250-255
Reset (5s)
4
4
Pan&tilt
speed
000-255
Pan&Tilt speed adjustment from fast to slow
5
5
Pan
000-255
0-540°pan movement
6
6
Tilt
000-255
0-280°tilt movement
7
Pan fine
000-255
16 bit pan movement
8
Tilt fine
000-255
16 bit tilt movement
9
7
Color wheel
000-009
White
010-019
Color1
020-029
Color2
030-039
Color3
040-049
Color4
050-059
Color5
060-069
Color6
070-079
Color7
080-089
Color8
090-099
Color9
100-109
Color10
110-119
Color11
120-129
Color12
130-139
Color13
140-149
Color14
150-199
1*14color mixing
200-229
Color wheel CCW rotation from slow to fast, Rainbow effect
230-255
Color wheel CW rotation from slow to fast, Rainbow effect
10
8
Gobo
000-009
White
010-019
Gobo1
020-029
Gobo2
030-039
Gobo3
040-049
Gobo4
050-059
Gobo5
060-069
Gobo6
070-079
Gobo7
080-089
Gobo8
090-099
Gobo9
100-109
Gobo10
